Basic Info.
Model NO.
TYC-NLB
Micron Rating
10um~1000um
Construction
Swen
Collar Type
Steel Ring/Plastic Ring
Feature
Anti-Static, Breathable
Application
Liquid Filtration
Transport Package
Carton
Specification
ISO9001
Trademark
Tianyuan
Origin
China
HS Code
591140000
Production Capacity
5000000PCS/Year
Product Description
Our liquid filter bags are produced of fabrics and neddle felts in different fineness according to your filtration process. They are well designed to meet your specific filtration requirements.
Features
Efficiency Ratings up to 99.98%...Provides absolute rated performance
Fully Welded Construction...Eliminates solids bypass
Zero-Bypass Bag Collar...Assures an optimum compression seal
Ratings from 0.2 to 600 Microns...Absolute or nominal ratings
Filter Bags - Liquid
Filter bags are manufactured for optimum filtration performance. They are made from carefully selected media, according to the specifications of the process industry. Various types of media are used such as needle felt, monofilament and multi-filament. They are effective in removing solid particulate from liquids where large volumes of contamination are present or where highly viscous fluids are required to be filtered. They offer an effective solution to many filtration problems.
Operation
Filtration takes place as the liquid flows from the inside of the filter bag to the outside.
Needle felt filter bags utilize the reliable mechanisms of depth filtration and have a high dirt holding capacity. Mesh filter bags utilize the well proven mechanisms of surface filtration and are effective in removing large solid particulate or agglomerates from the liquid flow.
Filter bag replacement is simple. All debris and contamination removed from the liquid is held inside the bag which is lifted from housing after opening the top lid or bowl and disposed of in accordance with environmental regulations.
Features & Benefits
High performance
Filtration rating from 1 to 200 Micron
Good for viscous fluid filtration
High flow rates
Low pressure drop
Broad chemical compatibility
Positive sealing arrangement with choice of materials
High dirt holding capacity
Simple maintenance
FDA Compliance
Features
Efficiency Ratings up to 99.98%...Provides absolute rated performance
Fully Welded Construction...Eliminates solids bypass
Zero-Bypass Bag Collar...Assures an optimum compression seal
Ratings from 0.2 to 600 Microns...Absolute or nominal ratings
Filter Bags - Liquid
Filter bags are manufactured for optimum filtration performance. They are made from carefully selected media, according to the specifications of the process industry. Various types of media are used such as needle felt, monofilament and multi-filament. They are effective in removing solid particulate from liquids where large volumes of contamination are present or where highly viscous fluids are required to be filtered. They offer an effective solution to many filtration problems.
Operation
Filtration takes place as the liquid flows from the inside of the filter bag to the outside.
Needle felt filter bags utilize the reliable mechanisms of depth filtration and have a high dirt holding capacity. Mesh filter bags utilize the well proven mechanisms of surface filtration and are effective in removing large solid particulate or agglomerates from the liquid flow.
Filter bag replacement is simple. All debris and contamination removed from the liquid is held inside the bag which is lifted from housing after opening the top lid or bowl and disposed of in accordance with environmental regulations.
Features & Benefits
High performance
Filtration rating from 1 to 200 Micron
Good for viscous fluid filtration
High flow rates
Low pressure drop
Broad chemical compatibility
Positive sealing arrangement with choice of materials
High dirt holding capacity
Simple maintenance
FDA Compliance
